Mechanical | Size: 90 x 96 x 63 mm (3.5 x 3.8 x 2.5”). PC104 compatible. |
Processor | Intel Core i3 |
Input Voltage | 10–15VDC (nominal 12 V DC) |
Bus Expansion | None |
Operating Temperature | -40° to +85°C |
Shock and Vibration | MIL-STD-202H |
Memory (RAM) | 16 GB DDR4 ECC |
Display | Intel UHD P630 Graphics |
Display | Two Mini DP++ outputs (3840 x 2160) |
Storage | SATA 6 Gb/s port. Dual available. |
Storage | 128 GB soldered-down NVMe. Larger sizes supported. |
Network | Two GbE ports (10/100/1000 auto-detect) |
USB | Two USB 3.1 / 2.0 ports |
USB | Four USB 2.0 host ports |
Serial I/O | Two COM ports |
Digital I/O | Eight TTL I/O Lines 3.3V |
Other I/O | I2C interface |
Operating System Compatibility | Compatible with most x86 operating systems including Windows 10/11 and Linux. |
See datasheet for full specifications
